Gas Furnace – 80% WFEL-C* (Low NOx)

EcoTemp residential equipment is AHRI-Certified and ensures year-round comfort. We offer a full line of heat pumps, air conditioners, furnaces and package units that are built to last and environmentally friendly. No matter what your needs, EcoTemp has the right fit for you.

Gas Furnace – 80% WFEL-C* (Low NOx)

Our ultra-low NOx gas furnace is an easy choice for California residents in the South Coast Air Quality Management District and San Joaquin Air Pollution Control District looking for a heating solution with reduced NOx emissions. This 80% AFUE furnace reliably heats your home while significantly reducing emissions that contribute to smog, acid rain, water quality deterioration and more.

  • 80% AFUE rating

Our ultra low NOx furnace designed for California brings the heat during winter with proven reliability and a 65% reduction in NOx emissions compared to a standard, low-NOx model. A variable speed blower motor delivers enhanced comfort all year long.

FEATURES & BENEFITS

  • Enhanced diagnostics with easy to read 3 digit display for faults and status
  • Flame roll-out sensors standard
  • Category I venting
  • Blocked vent switch
  • Louvered door
  • 24 VAC humidifier terminal
  • Electronic air cleaner terminal
  • Select sizes approved for twinning, refer to accessory kit listing
  • WFEL – Low NOx units are designed for California installations and can be installed in air quality management districts with a 40ng/J NOx emissions limit
  • Cabinet air leakage less than 2.0% at 1.0 in. w.c. and cabinet air leakage less than 1.4% at
  • Adjustable heating blower OFF delay
  • Factory set blower ON delay
  • 1-Year No Hassle Replacement™ Limited Warranty *
  • 5-Year Parts Limited Warranty *
  • Additional 5-Year Parts Limited Warranty upon timely registration *
  • 20 Year Heat Exchanger Limited Warranty *

* See warranty certificate for details and restrictions

SPECIFICATIONS

  • 80% AFUE
  • Multi 18-Speed, Constant Torque (MCT) ECM blower motor
  • Four-position furnace: upflow, horizontal right, horizontal left, downflow
  • Electronic control center
  • Adjustable heating air temperature rise, LED diagnostics and self test feature
  • Hot Surface Ignition (HSI)
  • WFEL is approved for use in Low NOx Air Quality Management Districts

*Low-NOx Models

Specifications

Physical

Blower Motor Type: Variable-Speed, Constant Airflow ECM
Blower Motor Speeds: Communicating Variable Speed
Blower Motor RPM: 1050
Maximum Pressure: 13.6
Gas Connection Size: 1/2
Heat Exchanger Type: Stainless Steel Tubular
Number Of Burners: 2
Ignition Type: Silicon Nitride Hot Surface
Configuration: Upflow;Downflow;Horizontal

Electrical

Cycle: 60
Phase: Single
Voltage: 115
Minumum Circuit Breaker: 15amp

Performance

BTU Input: 40000, 60000, 80000, 100000
BTU Output: 32000, 48000, 64000, 80000
AFUE: 80
Tonnage: 3, 4, 5
